    AutoEnginuity with Ford, GM, Dodge, & Chevrolet Enhanced

    AutoEnginuity with Ford, GM, Dodge, & Chevrolet Enhanced

    This package from AutoEnginuity will allow you to view diagnostic codes on EVERY engine, plus it allows you to have full bi-directional control on all the major domestics -- Ford, GM, Dodge, and Chevrolet. This package gives you the ability to perform tests such as:

    Ford Family - Supports over 7,900 sensors from 122 systems. This includes support for non-US models such as Ka, Mondo, Galaxy, and Fairline.

    • PATS Timed Key Programming ('96 - '08)
    • KOEO
    • KOER
    • Power Balance (CAN-based models)
    • EVAP Bay Test
    • Service Bleed (Non-CAN support not available with ProLine currently)
    • Buzz Injector
    • Cylinder Contribution Test
    • Switch Test
    • Glow Plug Test
    • System Self-Test
    • Low - and High Speed Fan
    • All Outputs On/Off
    • Injector Coding (1.8L and 2.0L)
    • KAM Reset
    • Misfire Monitor Neutral Profile Correction
    • Tire Size Programming up to 40" ('99-'03 7.3L, and '04-'07 6.0L trucks)
    • IVD Initialization
    • Steering Angle / Yaw Rate / Acceleration Sensor Reset ('03 Explorer and Lincoln LS)
    • Passenger Seat ReZero and Passenger Weight Reset
    • Power Seat Calibration Test
    • Audio Network Communication Test
    • Vehicle In-Motion IO Test
    • Front Wiper Self-Test
    • Rear Wiper Self-Test
    • Diesel Particulate Filter Reset, Clear EGR Adaptive Tables, and Clear Fuel Injector Adaptive Tables

    GM Family - Includes support for Buick, Cadillac, Chevrolet, GMC, Hummer, Oldsmobile, Pontiac, and Workhorse. Over 6,000 sensors from over 68 systems is supported. There are over 2,000 bi-directional command and system level tests that can be performed!

    • ABS Automated Bleed Routine (ProLine Connector)
    • Crank Variation Learn
    • Injector Flow Rate Programming (CAN-based Diesels)
    • Key Fob Programming
    • SDM Setup and Part Number Programming
    • Idle Learn
    • TDC Learn
    • Tire Pressure Sensor ID Programming (via CAN-based Remote Control Door Lock Receiver)

    Chrysler/Dodge/Jeep - Coverage includes diesel Cummins engines, Dodge Sprinters Vans, and much more!

    • EGR System Test
    • EVAP System Monitor Service Test
    • Erase All DTC Fault Codes
    • Generate Full Field Test
    • Gov & 3-4 Shift Valve Test - JTEC Only
    • Leak Detect Pump Test
    • Purge Vapors Test
    • Reset All Adaptive Memory Fuel Cells
    • Reset All Non-Volatile Memory
    • Reset CAM/Crank Misalignment
    • Reset CAM, Crank, and Sync Status Record
    • Reset Duty Cycle Monitor
    • Reset Engine Running Time Record
    • Reset Fuel Shut-off Record
    • Reset Intake Airflow Control Stepper Motor Position
    • Reset Trip Information
    • Set Sync Signal - JTEC Only
    • Set Minimum Throttle Position to Maximum
    • Torque Converter Clutch Test - JTEC Only
